THE INSTRUMENT

The TECHNOVATlON SR2017 is an online   multi- gas analyser and can measure up to eight different gases simultaneously. A variety of sensors can be connected which could include Electro chemical, NDIR, Pellistor and even industry standard 2 wire and three wire 4-20 mA transmitters for a wide range of parameters. The 128x64 pixel LCD display makes operation easy and user friendly. Facility for storage, Viewing of saved data on display. The instrument is known for its superior performance, simplicity of use and long service life.

FEATURES

      Eight sensors can be connected in the following configuration. Upto 6 Electrochemical. Plus upto 2 NDIR or Pelistor or 4-20 mA transmitters

      Name, location, Range and Resolution for each gas configurable

      128 x 64-pixel LCD back light display

      Trend analysis, Alarms Error and event viewing

      Two Alarms, their set point, Activation, Hysteresis are programmable for each channel.

      Common alarm relay also provided

      Outputs of RS-485, RS232 or USB or Ethernet.

APPLICATIONS

Process gas monitoring, Quality assurance, R&D applications, Purified BIO-gas. ETC

PRINCIPLE OF OPERATION

As a wide range of gases can be monitored, by selecting the appropriate sensor whole ordering, all the gases are not mentioned here. Albeit the more common ones are, O2, CO, H2S, SO2, Cl2 NO, NO2, C2H4, and other Toxic gases, Combustible Gases, NDIR sensors include CH4, CO2, Freon, etc. Transmitters for Pressure, Temperature, and Moisture.

All sensors can be inbuilt when gases are non flammable OR available on end of cable in metallic holder for hazardous applications.

STANDARD SPECIFICATIONS

Gases & Range    : Available on request

STANDARD SPECIFICATIONS CONTINUED

Display                  : 128 x 64 LCD with backlight

Sensor types         : Electrochemical, NDIR, 3 Wire industry standard 4-20mA transmitters.

Accuracy              : As per sensor selected

Resolution             : As per sensor selected

Power                    : 110 to 220VAC 50 -60 Hz

Box size                 : 220 x 160 x 110 mm

Weight                   : 7 kg

Box material          : Aluminum die cast
